用途：
※ 本機主要用於内衣模杯生產及其他同類產品的定型生產。
Function:
※ It is mainly used to mold foam bra cups，bra pads and other similar products.
特點：
※ 本機採用雙模結構，四導桿向，剛性好，導向精度高，合模平穩。
※ 特有溫度控制系統，運用可控硅移向觸發電流控制加熱，可使發熱更均勻，平穩，省電，節能效果佳。
※ 本機適用尺碼較大的罩杯加工，也可以適用於多對模杯的加工，配有自動抽煙裝置，工作臺面內置冷卻風扇，有利於成型模杯散熱。
Features
※ With double molding tables, four guiding pillars with good rigidity. High precision with guiding, stable in clamping moulds.
※ Special temperature control system and utilizing silicon controlled phase shifting triggering current to control heating, it can make the temperature more even and steady with remarkable energy-saving efficiency.
※ It is best suitable for molding European big sizes bra cups. Equipped with automatic smoke-exhausting devices, cooling fans installed in the inner part of worktable. It is environment friendly and benefit for heat elimination of molded bra cups.
技術參數：
Technical Specifications:
|
電源/功率
Power supply/power
|
380V/12W
|
|
電熱管規格
Heating tube size
|
Dia12x450mmx500W-220V
|
|
模臺尺寸
Dimension of the mould table
|
550mmx450mm
|
|
機臺尺寸
Dimension of the machine
|
1800mmx975mmx2400mm
|
|
適用物料
Applicable material
|
文胸、服裝等面料
Fabrics for bra and other garments
|
|
適用模具
Applicable mould
|
文胸棉杯模具
Moulds for foam cups
|
|
重量
Weight
|
900kg
|
|
